1300V Fast Switching Reverse-conducting Thyristor RCT
YZPST-SHR400R22 Fast Switching Reverse-conducting Thyristor
RCT FOR INVERTER AND CHOPPER APPLICATIONS
Features:
All Diffused Structure
Interdigitated Amplifying Gate Configuration
Blocking capabilty up to 1300 volts
Guaranteed Maximum Turn-Off Time
High dV/dt Capability
Pressure Assembled Device
Blocking - Off State
|
Device Type |
VDRM |
VDSM |
|
SHR400R22 |
1300 |
1300 |
VDRM = Repetitive peak off state voltage
VDSM = Non-repetitive peak off state voltage
(Non-repetitive<5ms, Tj=0～115℃)
|
Repetitive peak off state leakage |
IDRM |
35 mA |
|
Critical rate of voltage rise |
dV/dt |
1000 V/msec |
Conducting - on state
|
Parameter |
Symbol |
Min. |
Max. |
Typ |
Units |
Conditions |
|
RMS value of on-state current |
ITRMS |
|
630 |
|
A |
Nominal value |
|
Average on-state current |
IT(AV) |
|
400 |
|
A |
Continuous single-phase,half sine wave,180°conduction |
|
Peak one cycle surge on-state current(non repetitive) |
ITSM |
|
7200 |
|
A |
50Hz, sinusoidal wave- shape, 180o conduction, Tj = 115 oC |
|
I2t Limit Value |
I2t |
|
200x103 (On-Current) |
|
A2s |
|
|
31x103 (Reverse Current) |
||||||
|
Peak on-state voltage |
VTM |
|
3.0 |
|
V |
ITM =1250A; Tj = 25 oC |
|
Critical rate of rise of on-state current |
di/dt |
|
100 |
|
A/ms |
VD=1/2VDRM,ITM=800A f=60HZIGM=1.5A,diG/dt=1.0A/us,Tj=115℃ |
|
Average reverse current |
IR(AV) |
|
150 |
|
A |
Continuous single-phase,half sine wave,180°conduction |
|
RMS reverse currrnt |
IR(RMS) |
|
235 |
|
A |
|
|
Peak reverse voltage |
VRM |
|
2.5 |
|
V |
IRM=500A, Tj = 25 oC |
|
Peak one cycle surge reverse current(non repetitive) |
IRSM |
|
2500 |
|
A |
50Hz, sinusoidal wave- shape, 180o conduction, Tj = 115 oC |
|
Critical rate of rise of commutating off-state voltage |
(dv/dt)C |
200 |
|
|
A/ms |
ITM=2000A,tw=60us,IRM=1000A, ,VDM=1/2VDRM,Pulse width 60ms ,Tj=115℃, |
Gating
|
Parameter |
Symbol |
Min. |
Max. |
Typ. |
Units |
Conditions |
|
Peak gate power dissipation |
PGM |
|
20 |
|
W |
tp = 40 us |
|
Average gate power dissipation |
PG(AV) |
|
4 |
|
W |
|
|
Peak gate current |
IGM |
|
4 |
|
A |
|
|
Gate current required to trigger all units |
IGT |
|
200
|
|
mA
|
VD = 6 V;RL = 6 ohms;TC = 25 oC |
|
Holding current |
IH |
|
500 |
|
|
Tj = 25 oC ;RL = 6 ohms |
|
Gate voltage required to trigger all units |
VGT |
|
3.0 |
|
V |
VD = 6 V;RL = 6 ohms;TC = 25oC |
|
Peak non- trigger voltage |
VGD |
|
0.15 |
|
V |
Tj = 115 oC;VD=1/2VDRM |
For more information about YZPST-KS600A please download the PDF file above named " YZPST-SHR400R22(RCT) "
