YZPST-HVP12

YZPST-HVP-12.pdf

YZPST HIGH VOLTAGE DIODE IN PLASTIC PACKAGE PST_.pdf

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Specification

http://www.youtube.com/channel/UCZ3mV8GmGNcX4WcYEoWX-_g/featured

No.	Item	Symbol	Unit	Rating	Conditions
1	Repetitive Peak Reverse Voltage	VRRM	KV	16
2	Average Forward Current	IF (AV)	mA	750	Tamb=60 oC 50HZ Sine-half Wave Rectification Average Value
3	Forward Surge Current	IFSM	A	50	Tamb=25 oC 50HZ Sine-half Wave,One Shot
4	Reverse Surge Current	IRSM	μA	5	Pulse width 1ms triangle wave single pulse
5	Maximum Junction Temperature	Tjmax	oC	120
6	Storage Temperature	Tstg	oC	-40~+120

NO.

Item

Symbol

Unit

Rating

Test conditions

Forward Voltage Drop

VFM

IF(AV)=750mA

Normal Temperature Reverse Current

IRM1

μA

VRM=16KV

High Temperature Reverse Current

IRM2

μA

Tamb=100oC

VRM=16KV

Reverse Breakdown Voltage

IR=750mA

Reverse Recovery Time

trr

IF=IR=200mA, 90%

(Tamb=25 oC, unless otherwise specified

Application

Industrial microwave drying equipment,High Frequency Power,Ultrasound high frequency heat sealing machine power,Other electronic devices power rectifier.

YZPST can provide Following Equivalent List of high voltage diodes.

High voltage diodes

2CLG 100mA 10KV

2CLG 100mA 20KV

2CLG 100mA 15KV

2CL 500mA 12KV

2CL104 (350mA 12KV)

2CL106 (500mA 12KV)

HV600S10 (600mA 10KV)

HV600S12 (500mA 12KV)

High Frequency High Voltage Diode

2CL G 20mA 20KV 80ns
