YZPST-SR3KV

MAXIMUM      RATINGS      AND      ELECTRICAL      CHARACTERISTICS

(single-phase,half-wave,60HZ,resistive or inductive load rating at 25°C,unless otherwise stated)

Symbol

SR3KV

units

Maximum Recurrent Peak Reverse Voltage

VRRM

3000

V

Maximum RMSVoltage

VRMs

2100

V

Maximum DC blocking Voltage

VDC

3000

V

Minimum ReverseBreakdown Voltage    IR=100μA

V(BR)R

3100

V

Average ForwardRectified Current half-sinewave

IFAV

0.25

A

Peak Forward Surge Current 10ms half sine-wave

lFSM

15

A

Maximum Forward Voltage at 0.25A

VF

5.0

V

Non-repetitive peak reverse avalanche energy at leRR)=0.2A

ER

5.0

Maximum DC Reverse Current

at rated DC blocking voltage

Tj=25℃ Tj=125℃

lR

10.0 100.0

μA

Maximum Reverse Recovery Time          (Note1)

Trr

250

nS

Typical Thermal Resistance            (Note  2)

Rth(ja) Rth(jc)

45

25

℃/W

Typical Junction Capacitance          (Note  3)

Cj

10.5

pF

Storage and Operating Junction Temperature

Tstg,Tj

-55to+175

℃

Note:

1.Reverse Recovery Condition If=0.5A,Ir=1.0A,Irr =0.25A 2.Lead length I=10mm,TL=constant

3.Measured at 1.0 MHz and applied Vr=4.0V

Min

3000.00

Min

Max

10

5

250

Max

Condition

IR

VRRM

IF

Condition

Bin1@

100 μA

3000 V

0.25 A

If = 0.5A, Ir =1.0A, I rr =0.25A

Bin1@

Item

VRRM(V)

IR( μA)

VF(V)

TRR(ns)

Item

1

3889

0.198

2.281

115

2

3867

0.097

2.179

126

3

3866

0.316

2.172

120

4

3974

0.18

2.18

124

5

3883

0.202

2.21

123

6

3813

0.189

2.201

122

7

3747

0.164

2.252

112

8

3958

0.184

2.418

112

9

3851

0.111

2.137

125

10

3818

0.115

2.202

116

11

3991

0.125

2.231

122

12

3735

0.184

2.629

96

13

3913

1.104

2.239

118

14

3932

0.128

2.461

106

15

3899

0.11

2.203

122

Min

3735

0.097

2.137

96

Max

3991

1.104

2.629

126

Avg

3875.733

0.227133

2.26633

117.2667
