YZPST-ZP Series-ZP40
Product summary and primary technical information will be loaded from the product database.
Tip: include the part number, target voltage/current and application environment.
Downloads & technical files
Chip For Didoe 2200v-40mm
Symbol | Characteristic | Conditions | Temperature | Value | |
1 | IRRM | Repetitive peak reverse current | V=VRRM | Tj = 25°C | ≤ 10mA |
2 | IRRM | Repetitive peak reverse current | V=VRRM | Tj = 175°C | ≤ 70mA |
3 | VFM | On-state voltage | IT = 1500 A | Tj = 25°C | ≤ 1.16V |
D1 | 39.5~40 mm |
TK | 1.8~2.0mm |
D2 | 32mm |
D3 | NO |
D4 | NO |

This outline is for 40mm Diode fusion element.
Junction have double Overcoats, the outside is Red.
Cathode Surface Metal:10~15um Aluminium.
Anode surface Metal:molybdenum
