YZPST-SK60DTA16
P/N: YZPST-SK60DTA
3-phase bridge rectifier+ series thyristor
SK 60 DTA
Preliminary Data
Features
● Compact design
● One screw mounting
Heat transfer and isoIation
through direct copper bonded
aIuminium oxide ceramic (DBC)
● GIass passivated thyristor chips
● Reverse voItage up to 1600 V
● High surge currents
Typical Applications*
Soft starters
● Light controI
● Temperature controI
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Product description
P/N: YZPST-SK60DTA
3-phase bridge rectifier+ series thyristor
SK 60 DTA
Preliminary Data
Features
- Compact design
- One screw mounting
Heat transfer and isoIation
through direct copper bonded
aIuminium oxide ceramic (DBC)
- GIass passivated thyristor chips
- Reverse voItage up to 1600 V
- High surge currents
Typical Applications*
Soft starters
- Light controI
- Temperature controI
| VRSM V | VRRM, V DRM V | ID = 61 A (Ts = 80 ℃) |
| 900 | 800 | SK 60 DTA 08 |
| 1300 | 1200 | SK 60 DTA 12 |
| 1700 | 1600 | SK 60 DTA 16 |
