l tem

Performance Characteristics

Operating temperature range

-40℃~+105℃

-25~+105℃

Rated voltage range

16~100V

160~450V

Capacitance tolerance

±20%(120Hz,+20℃)

Leakage current

after 5 minutes,Whichever is smaller

 ( t g δ )

Rated voltage(V)

16

25

35

50

63-100

160-400

450

Dissipation factor

tgδ

0.5

0.4

0.35

0.3

0.2

0.15

0.2

(+20℃,120Hz)

Temperature Characteristics

UR (V)

16-100

160-200

250-450

(Impedance ratio at 120Hz)

ZZ,

4

4

4

Z4oc/Z,ot

15

Load life

After applying rated voltage with specified ripple current for 3000 hours +105℃ and then resumed 16 hours:

Capacitance change:±20% Initial measured value Leakage current:≤Initial specified value

Dissipation factor.≤2 times initial specified value

Shelf life

After storage for 1000 hours at+105℃ U,to be applied for 30 minutes and then resumed 16 hours

Capacitance change:±20%Initial measured value Leakage current:≤Initial specified value

Dissipation factor:≤Initial specified value
